LINEA 75 LV 1350LM 4000K CRI97 80° NO DIM CS WHITE
ILLUXTRONSpecifications
Stock In function of the available stock and the desired quantity, you will receive this product on working days and, if ordered before 16:30, the day after (only for Belgium). | On demand |
---|---|
Part number | 8716197226599 |
Reference | 915G03MW4M02 |
Brand | Illuxtron |
Family | Linea 75 |
Style The style that the design of the device has. | Timeless |
Location use | Interior |
Fixation location | Ceiling recessed |
Place of application | Ceiling interior recessed |
Possible setup The space where you can apply the device. | Bedroom, Desk / Office, Entrance / hall, Kitchen, Living room, Lounge |
Shape | Round |
Type recessed spot | Deep-seated with frame |
Colour This is the colour of which the device is mainly composed. | White |
RAL colour | RAL 9016 |
Applied materials These are the visible materials that make up the luminaire. | Die cast aluninium, Polycarbonate |
Light source included | Yes |
Type of light source | LED |
Integrated LED This is a built-in LED module. You cannot replace this yourself however the driver or LED module can be repaired. The device is repaired by the manufacturer. | Yes |
Number of light sources | 1 |
Lamp base This is the fitting of the lamp that fits into the device. | Ledmodule |
Average life span in hrs. | L90B10>60500 |
Macadam | SDCM: 3 |
Type of light The type of light indicates the effect of the light source. | Accent direct |
Type in brand | Spots recessed |
Colour temperature light Indicates the light colour of a light source. It is expressed in Kelvin. The higher the value the whiter the light. The lower the value, the yellower the light. | 4000K cool white |
Colour Rendering Index CRI Colour Rendering Index indicates how correctly a light source reproduces the colours it shines on. The higher the CRI, the more correctly the colours are rendered under the light source. | 97 |
Beam angle in ° This is the angle from which the light falls starting from the light source. | 80 |
Voltage/current | 220-240V |
Power factor | >0,95 |
Operating temperature | -20°C to +45°C |
(Max.) Watt / lamp | 13,8 |
Lumen 1st light source The total amount of visible light emitted by a light source. | 1350 |
Lumens per watt | 96 |
IP rating IP stands for "International Potection. The first digit indicates dust density. The second indicates water density. However, if a third digit is included, it refers to the impact resistance or 'I K' value. | IP20/65 |
Insulation class | II |
Dimensions | See picture |
Cover size in mm | 90 |
Mounting depth in mm | 60 |
Recessed opening shape | Round |
Installation dimensions in mm | 75 |
Thickness in mm | 2 |
Height in mm | 55 |
Dimmable With a dimmable device, you can control the brightness and/or light colour. | No |
More technical details | See technical data sheet and instructions |
